Corrugated cardboard

Materials

  • Single wall
  • Double wall
  • Triple wall
  • B-Flute
  • E-Flute
  • F-Flute

Brands

  • Smurfit Kappa
  • Flapor
  • Mondi
  • Antalis
  • DSSmith
  • Model

Tools

for processing corrugated cardboard

7 Product(s) found
Sorry, no suitable results found for these filters.
1 / 7
CTT1
Creasing tool type 1

Creasing of single-wall corrugated board. Pressure settings are individually adjustable, with or against the corruga ...

CTT1
Creasing Tool Type 1 - CTT1

The CTT1 is perfect for processing single-wall corrugated board. The tool accommodates crease wheels with a diameter of 61 mm/2.4 in and a width of 20 mm/.8 in. Fully supported by the cutter software, the tool produces high-quality creases both with and against the corrugation without tearing or cracking the top sheet. The crease wheels simply snap into the holder, making them very easy to insert and replace.

  • Clean creases without tearing
  • Directional pressure adjustments
  • Crease wheel diameter: 61 mm / 2.4 in
  • Crease wheel width: 20 mm/.8 in
  • Crease wheels snap into holder
  • Compatible with G3, S3, D3
Product information
Materials

Corrugated cardboard

CTT3
Creasing Tool Type 3

Creasing of double- and triple-wall corrugated board. Pressure settings are individually adjustable, with or against ...

CTT3
Creasing Tool Type 3 - CTT3

The CTT3 is designed for creasing double- and triple-wall corrugated board. Accommodates crease wheels with a diameter of 90 mm/3.5 in and a width of 28 mm/1.1 in. The tool produces high-quality creases both with and against the corrugation without tearing or cracking the top sheet. The crease wheels simply snap into the holder, making them very easy to insert and replace.

  • Clean creases without tearing
  • Directional pressure adjustments
  • Crease wheel diameter: 90 mm / 3.5 in
  • Crease wheel width: 20 mm/.8 in
  • Crease wheels snap into holder
  • Compatible with G3, D3
Product information
Materials

Corrugated cardboard

PTT
Perforating Tool Type 1

Ideal tool for creating precise perforations.

PTT
Perforating Tool Type 1 - PTT

The PTT1 is designed to accommodate perforating blades. This tools can create perf lines more efficiently than an oscillating tool. Perforations are used, among other things, to facilitate folding/bending along crease lines. This allows for greater precision. In addition to traditional materials such as corrugated cardboard, folding carton, and PP (polypropylene), vinyl can also be perforated using this tool.

  • Suitable for corrugated cardboard, folding carton, polypropylene, vinyl
  • High-quality perforations
  • High processing speeds
  • Wide range of perforating blades available from Zünd
  • Compatible with G3, S3, D3
Product information
Materials

Cardboard

Corrugated cardboard

POT
Pneumatic Oscillating Tool

Powerful oscillating tool with extended stroke for cutting tough, dense materials up to 110 mm / 4.3 in thick.

POT
Pneumatic Oscillating Tool - POT

The Pneumatic Oscillating Tool is an air-driven tool particularly well suited for cutting tough, dense materials but can also handle soft, thicker ones. The use of considerable air pressure in combination with an 8mm stroke gives this tool the force required for tough applications.

The POT is available in two versions, with 0.6 mm or 1.5-mm thick blades. With sufficient beam clearance, it is possible to process materials up to 110 mm / 4 in thick. A wide range of possible applications are supported with a variety of compatible oscillating blades.

  • High-performance cutting tool with 8 mm stroke
  • Powerful, low-maintenance pneumatic tool
  • Two versions available for 0.6 mm or 1.5 mm blade thicknesses
  • Compatible with G3, S3, D3, L3
Product information
Materials

Rubber

Twin-wall sheets

Cardboard

Leather

Foam / 110 mm foam

Corrugated cardboard

PCT
Press Cutting Tool

Cutting and compressing corrugated board in one step.

PCT
Press Cutting Tool - PCT

High processing speeds and high-quality results equal to die cutting: The PCT tool cuts corrugated cardboard up to 7 mm thick and simultaneously compresses the material with a special glide shoe.

The press cutting tool has been developed for economical cutting of corrugated cardboard up to a thickness of 7 mm. During the cutting process, a specially designed glide shoe compresses the material along the cut lines. The pressure exerted on the corrugated cardboard enables the use of drag knives and facilitates high processing speeds.

  • Special glide shoe for high-quality results equal to die-cutting
  • Very high processing speeds
  • Simple, precise depth adjustment
  • Fully supported in Zünd Cut Center - ZCC
  • Maximum material thickness: 7 mm
  • Suitable for flat-stock drag knives
  • Compatible with G3, D3, and S3
Product information
Materials

Corrugated cardboard

UCT
Universal Cutting Tool

Universal cutting tool for materials up to 5 mm thick.

UCT
Universal Cutting Tool - UCT

The Universal Cutting Tool is perfect for through-cutting various materials up to 5 mm/3/16 in thick. The use of drag knives allows for very high processing speeds. Compared to motor-driven tools, the UCT is very inexpensive to purchase and maintain. A spring-loaded glide shoe permits cutting very fine details. Optionally, a fixed glide shoe can be used for cutting at set depths.

  • Wide assortment of Zünd drag knives available
  • Very high processing speeds
  • Compatible with G3, S3, D3, L3
Product information
Materials

Vinyl

Twin-wall sheets

Cardboard

Textiles

UDT
Universal Drawing Tool

Drawing tool for use with widely available, standard pen inserts in various line thicknesses.

UDT
Universal Drawing Tool - UDT

The Universal Drawing Tool is a cost-effective tool for precisely marking/labeling materials including fabric, leather, rubber, and Teflon. This tool is used to draw assembly marks, line symbols, and text. Drawing/plotting is possible in any orientation.

The UDT is very cost-effective since it accommodates readily available, standard drawing/plotting tools such as felt-tip and ballpoint pencartridges available in various line widths.

  • This tool is used to draw assembly marks, line symbols, and text.
  • Compatible with G3, S3, D3
Product information
Materials

Vinyl

Rubber

Leather

Paper

Modules

1 Product(s) found
Sorry, no suitable results found for these filters.
UM
Universal module

Universal carrier modules for a wide range of tools.

UM
Universal module

The Universal Modules are widely applicable carrier modules designed to accommodate many different tools. The versatility of these modules makes it very cost-effective to adapt the cutting system to changing production requirements.

A bayonet lock allows for quick tool changes without a need for a screwdriver. A new or different tool can be set up with little effort and made ready for use. Modules can be operated in pressure or position mode. For different applications, the Universal Module is available in four different versions.

  • Exceedingly fast tool changes
  • Tool detection
  • Two operating modes: pressure/position
Product information
Module versions

UM-S (S3, L3)
UM-ZS (G3, D3)



UM-ZP (G3, D3)
UM-120 (G3)
UM-60L (G3, D3)
