D3 Digital Cutter

With low weight and short strokes/quick tool lifts, this module offers very high cutting speeds. The module also impresses with simple operation, rapid tool changes, and very high precision.

Depending on the application, you can choose between two different processing modes: in pressure mode, the module exerts constant pressure, adjustable from 30 to 1,500 grams, on the substrate. This results in precise, clean cuts in e.g. pressure-sensitive vinyl without damage to the liner material. In position mode, the tool through-cuts the material at a pre-set depth.

• Kiss-cutting and through-cutting of all commonly used vinyls, films, etc.
• Clean, precise cutting of self-adhesive vinyl without damage to liner
• Compatible with S3

Cut & Seal - cutting and edge sealing in one

Soft Signage is an extremely versatile medium for POP/POS applications and is making inroads into many applications previously dominated by paper, PVC, and other materials. For polyester fabric applications, Zünd offers the Laser Module - LM 100W. It cuts and seals the edges, all in the same process. Frayed edges become a thing of the past. The Laser Module eliminates tedious manual labor, increases cutting precision, and reduces production time. The LM 100W also produces consistently flawless edges with perfect repeatability.

• CO2 laser with 100W power
• For polyester fabrics up to 2 mm thick
• Sealed edges prevent fraying
• Perfectly safe operation with Class 1 laser
• Compatible with G3

Zünd marking modules accommodate a variety of pen and ink inserts. Typical applications include plotting die-lines with ink on polyester film, marking seams on leather with water-soluble silver pens, and labeling parts or patterns with ballpoint pen. The Marker Module is compatible with all drawing/plotting Inserts available from Zünd.

• Simple handling
• Plotting/drawing of die-lines, seams, patterns, guidelines
• Wide assortment of cost-effective drawing tools available from Zünd

The punching modules are used to punch leather, rubber, and various textiles remarkably fast. This module includes independently operating punches that accommodate a variety of punch tools. The punches rotate as they penetrate the material, which creates cleanly and precisely cut holes even in tough materials up to approx. 6 mm thick. Advantages of this processing method are high capacity and very good, consistent hole quality.

• Excellent, consistent hole quality
• Up to 8 holes per second
• Wide assortment of 0.5 – 5.5 mm Ø punches available from Zünd
• Reliable waste removal into integrated receptacle
• Depending on module version, additional notching, marking, or piercing functions

The centerpiece of all Zünd router modules is a high-performance high-frequency spindle. Depending on applications and requirements, versions from 1 to 3.6 kW are available.

• Routing, engraving, polishing with one and the same module
• Capable of processing a wide range of materials
• Active cooling for reliable heat dissipation
• Efficient dust extraction for clean operation
• Designed for 24/7 operation
• Wide assortment of Zünd router bits available

The Universal Modules are widely applicable carrier modules designed to accommodate many different tools. The versatility of these modules makes it very cost-effective to adapt the cutting system to changing production requirements.

A bayonet lock allows for quick tool changes without a need for a screwdriver. A new or different tool can be set up with little effort and made ready for use. Modules can be operated in pressure or position mode. For different applications, the Universal Module is available in four different versions.

• Exceedingly fast tool changes
• Tool detection
• Two operating modes: pressure/position

The CTT1 is perfect for processing single-wall corrugated board. The tool accommodates crease wheels with a diameter of 61 mm/2.4 in and a width of 20 mm/.8 in. Fully supported by the cutter software, the tool produces high-quality creases both with and against the corrugation without tearing or cracking the top sheet. The crease wheels simply snap into the holder, making them very easy to insert and replace.

• Clean creases without tearing
• Directional pressure adjustments
• Crease wheel diameter: 61 mm / 2.4 in
• Crease wheel width: 20 mm/.8 in
• Crease wheels snap into holder
• Compatible with G3, S3, D3

The CTT2 is a universally applicable crease tool. Accommodates a wide range of crease wheels for folding carton, polypropylene, twin wall sheets, etc.

• Clean creases without tearing
• Directional pressure adjustments
• Compatible with G3, S3, D3

The CTT3 is designed for creasing double- and triple-wall corrugated board. Accommodates crease wheels with a diameter of 90 mm/3.5 in and a width of 28 mm/1.1 in. The tool produces high-quality creases both with and against the corrugation without tearing or cracking the top sheet. The crease wheels simply snap into the holder, making them very easy to insert and replace.

• Clean creases without tearing
• Directional pressure adjustments
• Crease wheel diameter: 90 mm / 3.5 in
• Crease wheel width: 20 mm/.8 in
• Crease wheels snap into holder
• Compatible with G3, D3

The Driven Rotary Tool is designed for cutting all manner of textiles reliably and economically. The material is cut with a motor-driven ten-segmented blade. The blade geometry reduces the drag force on the material considerably and also helps cleanly sever thread or fiber. This processing method produces clean, precise cuts even on very loose, coarsely knit materials.

Choice of two RPM setting depending on the application. Also suitable for cutting materials with low melting points.

• Use of rotary blades reduces drag on the material
• Choice of 2 RPM settings (20,000/12,000 rpm)
• Clean separation of each thread or fiber
• Compatible with G3, S3, D3, L3

The Electric Oscillating Tool is suitable for cutting soft to medium-density materials. The high oscillating frequency enables high processing speed and efficient throughput.

Depending on the application, the EOT is available with 0.5 mm or 1.0 mm stroke. To accommodate different substrates and levels of detail, Zünd offers a wide range of both flat and pointed oscillating blades.

• Depending on application, available with 0.5 mm or 1.0 mm stroke
• Perfect for cutting detailed contours
• Very high stroke frequency
• High processing speeds
• Compatible with G3, S3, D3, L3

The Electric Oscillating Tool is ideal for efficiently processing materials such as honeycomb display board, thick cardboard, and tough leather. This high-performance tool is equipped with a powerful air-cooled motor. With an extended, 2.5 mm stroke andhigh oscillating frequency, the EOT-250 is capable of processing challenging materials at very high speeds. Zünd offers a wide variety of high-quality blades for use with the EOT-250.

• 2.5 mm stroke
• Very high processing speeds
• Wide range of Zünd oscillating blades available
• Compatible with G3, S3, D3, L3

The Ink Jet Tool - IJT enables the use of inkjet printing devices on G3 cutters. This allows for cutting and part marking in the same production workflow. The tool is used to mark/label cut parts with text or barcodes as well as to draw lines. The applications for this tool are numerous and range from product tracking (track and trace) to optimizing logistics and quality control.

• Flexible marking system with high print quality
• Very high printing speeds
• Printing is possible at any angle
• Certified inks available for aerospace applications
• Compatible with G3 M-1600, M-2500, L-2500, L-3200, and XL-1600

Perfect cutting depth is essential for any vinyl application, especially in kiss-cutting. The variable, adjustable pressure of the kiss-cut tool enables precise cutting of vinyl and film without damage to the liner material.

In addition to all standard vinyls and films up to 3 mm thick, the tool is also suitable for cutting thin paper and cardboard. A fixed glide shoe is included with the tool. It is used for through-cutting cardboard and Diamond Grade vinyl.

• Two processing methods: kiss-cutting & through-cutting
• Max. Material thickness: 3 mm
• Precise depth control
• Clean cuts make for easy weeding
• Special glide shoe available for processing Diamond Grade
• Compatible with G3, S3, D3

The Passepartout Tool is the ideal tool for creating precise 45 ° bevel cuts for mat-cutting and picture-framing applications. It is particularly suitable for processing cardboard and polymer materials up to 5 mm/ 3/16 in thick.

An adjustment gauge facilitates precise positioning of the blade in the holder. This enables perfect cuts and very high repeatability.

• Precise depth control
• Adjustment gauge included
• Processes cardboard and polymer materials up to 5 mm thick
• Compatible with G3, S3, D3

The PTT1 is designed to accommodate perforating blades. This tools can create perf lines more efficiently than an oscillating tool. Perforations are used, among other things, to facilitate folding/bending along crease lines. This allows for greater precision. In addition to traditional materials such as corrugated cardboard, folding carton, and PP (polypropylene), vinyl can also be perforated using this tool.

• Suitable for corrugated cardboard, folding carton, polypropylene, vinyl
• High-quality perforations
• High processing speeds
• Wide range of perforating blades available from Zünd
• Compatible with G3, S3, D3

The Pneumatic Oscillating Tool is an air-driven tool particularly well suited for cutting tough, dense materials but can also handle soft, thicker ones. The use of considerable air pressure in combination with an 8mm stroke gives this tool the force required for tough applications.

The POT is available in two versions, with 0.6 mm or 1.5-mm thick blades. With sufficient beam clearance, it is possible to process materials up to 110 mm / 4 in thick. A wide range of possible applications are supported with a variety of compatible oscillating blades.

• High-performance cutting tool with 8 mm stroke
• Powerful, low-maintenance pneumatic tool
• Two versions available for 0.6 mm or 1.5 mm blade thicknesses
• Compatible with G3, S3, D3, L3

The extremely robust and powerful Power Rotary Tool is designed specifically for reliable, economical cutting of challenging materials. The materials that can be processed with this tool range widely, from hard fiberglass to extremely tough aramid fibers. Choice of 3 RPM settings (to 100%, 75%, 50% of the maximum). This permits cutting very tough materials as well as those with low melting points.

Positive air pressure protects against dust and debris from e.g. carbon fiber, while also cooling the motor.

• Use of rotary blades reduces drag on the material
• Choice of 3 RPM levels
(16.000/12.000/8.000)
• Low-impact processing of materials with low melting points
• Clean, precise cuts and high throughput
• Compatible with G3, D3

High processing speeds and high-quality results equal to die cutting: The PCT tool cuts corrugated cardboard up to 7 mm thick and simultaneously compresses the material with a special glide shoe.

The press cutting tool has been developed for economical cutting of corrugated cardboard up to a thickness of 7 mm. During the cutting process, a specially designed glide shoe compresses the material along the cut lines. The pressure exerted on the corrugated cardboard enables the use of drag knives and facilitates high processing speeds.

• Special glide shoe for high-quality results equal to die-cutting
• Very high processing speeds
• Simple, precise depth adjustment
• Fully supported in Zünd Cut Center - ZCC
• Maximum material thickness: 7 mm
• Suitable for flat-stock drag knives
• Compatible with G3, D3, and S3

The raster method has emerged as the preferred process for creating tactile/Braille signage for the blind and visually impaired. The process is quite simple: the router drills holes into the substrate, and the Raster Braille Tool automatically inserts spheres. Because the spheres are securely encased, the resulting Braille is very durable and wear resistant.

The Raster Braille Tool is perfectly coordinated with Zünd’s routing/engraving tools, which makes the process very efficient.

• Secure fit of spheres in the substrate
• Compatible with G3, S3, D3

The Scoring Cutting Tool is used for scoring and through-cutting a wide range of materials up to 5 mm / 3/16 in thick. Depending on whether the material needs to be through-cut or scored, the blade is pneumatically extended or retracted. All flat-stock drag knives Zünd offers can be used with the SCT. An optional, spring-loaded glide shoe is available for processing challenging materials.

• Very high processing speeds
• The blade is pneumatically extended/retracted
• Can be used with all flat-stock drag knives Zünd offers
• Spring-loaded glide shoe available as option
• Compatible with G3, S3, D3

The Universal Cutting Tool is perfect for through-cutting various materials up to 5 mm/3/16 in thick. The use of drag knives allows for very high processing speeds. Compared to motor-driven tools, the UCT is very inexpensive to purchase and maintain. A spring-loaded glide shoe permits cutting very fine details. Optionally, a fixed glide shoe can be used for cutting at set depths.

• Wide assortment of Zünd drag knives available
• Very high processing speeds
• Compatible with G3, S3, D3, L3

The Universal Drawing Tool is a cost-effective tool for precisely marking/labeling materials including fabric, leather, rubber, and Teflon. This tool is used to draw assembly marks, line symbols, and text. Drawing/plotting is possible in any orientation.

The UDT is very cost-effective since it accommodates readily available, standard drawing/plotting tools such as felt-tip and ballpoint pencartridges available in various line widths.

• This tool is used to draw assembly marks, line symbols, and text.
• Compatible with G3, S3, D3

At the heart of the URT is a 300 W router spindle which operates at up to 80,000 rpm, depending on material and application. In combination with the many compatible bits Zünd offers, this makes for a powerful, widely applicable routing solution. Besides processing softer materials, the URT can also handle more challengins, denser ones in multiple passes.

The URT can easily be converted from a router to an engraving tool. In engraving mode, the height of the tool can be precisely adjusted with a micrometer screw. This ensures precision engraving, with consistent line widths and depths.

The airflow from the well-designed dust-extraction system effectively cools both the router bit and spindle, which significantly increases their longevity.

• Routing and engraving with one tool
• Consisten, precise control of routing depth
• 300 Watt router bit spindle with up to 80,000 rpm
• Stepless adjustable speed
• Wide assortment of Zünd router bits available
• Compatible with G3, S3, L3, D3

The V-Cutting Tool is the perfect tool for producing complex, three-dimensional structural designs made of cardboard, foamcore materials or corrugated/honeycomb display board. A well thought-out design allows for quick tool changes and easy, precise angle adjustments.

The VCT1 can cut at seven different angles (0 °, 5 °, 10 °, 15 °, 22.5 °, 30 °, 45 °).

• Simple, precise angle adjustments
• Produces cuts at seven different angles
• Very quick blade changes
• Compatible with G3, S3, D3

The V-Cutting Tool is the perfect tool for producing complex, three-dimensional structural designs made of cardboard, foamcore materials or corrugated/honeycomb display board. A well thought-out design allows for quick tool changes and easy, precise angle adjustments.

The VCT2 can cut at seven different angles (0°, 5°, 10°, 15 °, 22.5°, 30°, 45°).

• Simple, precise angle adjustments
• Produces cuts at seven different angles
• Very quick blade changes
• Compatible with G3, D3

The Wheel Knife Tool is an efficient, cost-effective tool option for single-ply cutting of glass and carbon fiber as well as technical textiles. The use of HSS steel blades in this tool allows for very high processing speeds and a clean, efficient cutting process.

Cutting is done in pressure mode. The pressure settings can be adjusted to precisely match the material properties and desired cut quality. A special PU (polyurethane) underlay is used in conjunction with this tool to prevent damaging the cutting surface.

• High cutting speeds
• Uses rotary, high-speed steel blades (HSS)
• Processing possible without vacuum hold-down
• Clean, efficient cutting process
• Special polyurethane cutting underlay
• Compatible with G3, D3
